Developing CEGMA: how working on old code can drive you mad and some tips on how to avoid this

Today marks the day when the original paper that describes the CEGMA software (Core Eukaryotic Gene Mapping Approach) becomes my most cited paper (as tracked by Google Scholar):

Does this fact make me happy? Not really. In fact, you may be surprised to learn that I find working on CEGMA a little bit depressing. I say this on a day when, purely coincidentally, I am releasing a new version of CEGMA. Why the grumpy face Keith? (I hear you ask). Let's take a trip down memory lane to find out why:

  • Early 2004: A paper is published that describes the KOGs database of euKaryotic Orthologous Groups.
  • Early 2005: I become the first person to join the Korf Lab after Ian Korf moves to Davis in 2004.
  • Mid 2005: Genís Parra becomes the second person to join the lab.
  • 2005–2006: The three of us work on the idea which became CEGMA. This project was primarily driven forward by Genís; during this time our initial CEGMA manuscript was rejected by two journals.
  • Late 2006: Our CEGMA paper was accepted!
  • Early 2007: CEGMA paper is published — as an aside, the URL for CEGMA that we include in the paper still works!
  • 2007: We work on the CEGMA spin-off idea: that it can be used to assess the 'gene space' of draft genomes.
  • 2008: Write new manuscript, get rejected twice (again), finally get accepted late 2008.
  • Early 2009: The 2nd CEGMA paper gets published!
  • Mid 2010: Genís leaves the lab.

By the time Genís left Davis, our original CEGMA paper had been cited 11 times (one of which was by our second CEGMA paper). I think that we had all expected the tool to have been a little more popular, but our expectations had been dampened somewhat by the difficulties in getting the paper published. Anyway, no sooner than Genís had left the lab, then the paper started getting a lot more attention:

Growth in citations to the two CEGMA papers.

This was in no doubt due to its use as a tool in the Assemblathon 1 paper (of which I was also involved), a project that started in late 2010. However, any interest generated from the Assemblathon project probably just reflected the fact that everyone and their dog had started sequencing genomes and producing — how best to describe them? —'assemblies of questionable quality'.

This is also about the time when I started to turn into this guy:

This was because it had fallen on me to continue to deal with all CEGMA-related support requests. Until 2010, there hadn't really been any support requests because almost no-one was using CEGMA. This changed dramatically and I started to receive lots of emails that:

  • Asked questions about interpreting CEGMA output
  • Reported bugs
  • Asked for help installing CEGMA
  • Suggested new features
  • Asked me to run CEGMA for them

I started receiving lots of the latter requests because CEGMA is admittedly a bit of a pig to install (on non Mac-based Unix systems at least). In the last 6 months alone, I've run CEGMA 80 times for various researchers who (presumably) are unable to install it themselves.

After the version 2.3 release — necessary to transition to the use of NCBI BLAST+ instead of WU-BLAST — and 2.4 release — necessary to fix the bugs I introduced in v2.3! — I swore an oath never to update CEGMA again. This was mostly because we no longer have any money to work on the current version of CEGMA. However, it was also because it is not much fun to spend your days working on code that you barely understand.

It should be said that we do have plans for a completely new version of CEGMA that will — subject to our grant proposal being successful — be redeveloped from the ground up, and will include many completely new features. Perhaps most importantly — for me at least — a version 3.0 release of CEGMA will be much more maintainable.

And now we get to the main source of my ire when dealing with CEGMA. It is built on a complex web of Perl scripts and modules, which make various system calls to run BLAST, genewise, geneid, and hmmsearch (from HMMER). I still find the scripts difficult to understand — I didn't write any of the original code — and therefore I find it almost impossible to maintain. One of the reasons I had to make this v2.5 update is because the latest versions of Perl have deprecated a particular feature causing CEGMA to break for some people.

Most fundamentally, the biggest problem with CEGMA (v2.x) is that it is centered around use of the KOGs database, a resource that is now over a decade old. This wasn't an issue when we were developing the software in 2005, but it is an issue now. Our plans for CEGMA v3.0 will address this by moving to a much more modern source of orthologous group information.

In making this final update to v2.x of CEGMA, I've tried adopting some changes to bring us up to date with the modern age. Although the code remains available from our lab's website, I've also pushed the code to GitHub (which wasn't in existence when we started developing CEGMA!). In doing this, I've also taken the step to give our repository a DOI and therefore make the latest version citable in its own right. This is done through use of Zenodo.

Although I hope that this is the last thing that I ever have to write about CEGMA v2.x, it is worth reflecting on some of the ways that the process of managing and maintaining CEGMA could have been made easier:

  1. Maintain documentation for your code that is more than just an installation guide and a set of embedded comments. From time to time, I've had some help from Genís in understanding how the code is working, but the complexity of this software really requires a detailed document that explains how and why everything works the way it does. There have been times when I have been unable to help people with CEGMA-related questions because I still can't understand what some of the code is doing.
  2. Start a FAQ file from day one. This is something that, foolishly, I have only recently started. I could have probably saved myself many hours of email-related support if I had sorted this out earlier.
  3. Put your code online for others to contribute to. Although GitHub wasn't around when we started CEGMA, I could have put the code up there at some point before today!
  4. Don't assume that people will use a mailing list for support, or even contact you directly. One thing I did do many years ago, is set up a CEGMA mailing list. However, I'm still surprised that many people just report their CEGMA problems on sites like SEQanswers or BioStars. I probably should have started checking these sites earlier.
  5. Don't underestimate how much time can be spent supporting software! I probably should have started setting aside a fixed portion of time each week to deal with CEGMA-related issues, rather than trying to tackle things as and when they landed on my doorstep.
  6. Assume that you will not be the last person to manage a piece of software. There are many things you can do to start good practices very early on, including using email addresses for support which are not tied to a personal account, ensuring that your changes to the code base have meaningful (and helpful) commit messages, and making sure that more than one person has access to wherever the code is going to end up.

In some ways it is very unusual for software to have this type of popularity where people only start using it several years after it is originally developed. But as CEGMA shows, it can happen, and hopefully these notes will serve as a bit of a warning to others who are developing bioinformatics software.
